JJY:023146720008

Ширина, мм

0.1

Артикул

JJY:023146720008

Базовая единица

шт

Производитель

Siemens

Глубина, мм

0.3

Длина, мм

0.075

Количество в упаковке

1

Описание необрезанное

Fa. Heine Breaking resistor FOR POWERMODULE FSA P_MAX=750W/12S/5% ED R=200 OHM P_DAUER=37,5W Accessories for inverters, braking resistor for PM240-2 Power Module for modular SINAMICS G120 inverters. Excess energy in the DC link is dissipated in the braking resistors. They are intended for use with PM240-2 and PM240 Power Modules (mounted next to the Power Modules). These Power Modules are equipped with an integrated braking chopper and cannot regenerate energy back to the line supply. For regenerative operation, e.g. the braking of a flywheel mass with high moment of inertia, a braking resistor must be connected to convert the resulting energy into heat. The braking resistors for Power Modules, frame sizes FSD to FSGX, should be placed outside the control cabinet or outside the electrical room so that the heat is dissipated away from the Power Modules. This reduces the level of air conditioning required. Every braking resistor is equipped with a temperature switch. The temperature switch should be evaluated i

Минимальный заказ

1

Тип компонента/запасная часть

Тормозное сопротивление
